| Dimension.(L×W×H)(mm) | 1920×670×1060 |
| Wheel base(mm) | 1245 |
| Min Ground clearance(mm) | 130 |
| Seat height(mm) | 765 |
| Turning angle | ＜48° |
| Min turning radius(mm) | 1940 |
| Front/Rear sprocket teeth | 14/38 |
| Gearshift | 4-forward |
| Fuel tank(L) | 4L |
| Fuel Type | gasoline |
| Max. Load Capacity(kg) | 150 |
| Dead Weight(kg) | 115kgs |
| Brake Mode： | Front Wheel | Disc brake |
| Rear Wheel | Drum brake |
| Brake Operation Mode | Front Wheel | Hand clip |
| Brake Operation Mode | Rear Wheel | Kick |
| Wheel Rim Type | Aluminum Front: 2.50x13 |
| Aluminum Rear: 2.50-13 |
| Tire type | with tube |
| Front tire | 110/90-13 |
| Rear tire | 110/90-13 |
| Headlight | 12V 18W/18W（double） |
| Winker | 12V 10W |
| Battery（mm） | 12N4-3B 120×70×92 with acid |
| | |
| Engine Model | 154FMI |
| Engine Type | OHC, Mono-cylindrical 4-stroke, air-cooled |
| Start | Electric and kick |
| Ignition | CDI |
| Bore×Stroke | 54x55.5 |
| Displacement(ml) | 127 |
| Compression rate | 8.7：1 |
| Magneto | 12V 6 head, full phase |
| Oil Capacity(ml) | 1000 |
| Spark plug | D8TC |
| Spark clearance(mm) | 0.6~0.7 |
| Valve clearance(mm) | 0.05~0.06 |
| Lubriation type | Press and splash |
| Carburetor | PZ20 |
| Transmission | Constant mesh, 4-forward, with high shift protection |
| Clutch type | Automatic, wet type, offcenter |
| Initial rate | 3.722 |
| Gears rate | 1st: 2.833,2nd: 1.705,3rd: 1.238,4th: 0.96 |
| Final trans | Chain |
| Rotation direction | Facing shaft, unclock wise |
| Size(mm) | 380×367×505 |
| Net Weight(kg) | 27 |
| Max Power | 6.4KW(7500r/min±5%) |
| Max Torque | 9.5N·m(5000-6500r/min) |
| Min fuel comsumption(g/kw.h) | 367 |
| | |
| | |
| Load Quantity | 40HQ | 105 units |
